SA 516 Grade 70 Steel Plates: The Complete Guide for Pressure Vessels & Boilers
ASTM/ASME SA 516 Grade 70 is the world's most widely used carbon steel plate for moderate- and lower-temperature pressure vessel service. This guide explains what makes it the default choice for boilers, heat exchangers, and oil & gas storage tanks, and what to verify before you buy.
What is SA 516 Grade 70?
SA 516 Grade 70 is a Pressure Vessel Quality (PVQ) carbon steel plate engineered for welded pressure vessels operating at moderate to lower temperatures. It offers an excellent combination of strength and notch toughness, which is why it has become the standard material specification for boiler shells, heat exchanger shells, and gas storage tanks across the process and power industries.
As-Rolled vs Normalized Condition
Normalizing is a heat treatment that refines the steel's grain structure to improve impact resistance, particularly at lower temperatures. Normalized SA 516 Gr 70 is typically required for critical applications, plates thicker than 40mm, or vessels intended for low-temperature service. Convergence Steel stocks both as-rolled and normalized plates to match your design code requirements.
HIC Testing & NACE MR0175 Compliance
For sour service applications in the oil and gas industry — where hydrogen sulfide is present — plates must resist Hydrogen Induced Cracking (HIC). Convergence Steel can supply SA 516 Gr 70 that is HIC tested and compliant with NACE MR0175, ensuring resistance to corrosion and cracking in hydrogen-rich, sour environments.
Chemical Composition & Mechanical Properties
SA 516 Gr 70 controls carbon at a maximum of 0.27%, manganese between 0.85–1.20%, and silicon between 0.15–0.40%, with phosphorus and sulphur each capped at 0.035%. Mechanically, it delivers a tensile strength of 485–620 MPa, minimum yield strength of 260 MPa, and elongation of 17% minimum over a 200mm gauge length (21% over 50mm).
Quality Assurance: MTCs, UT and Certification
Every genuine SA 516 Gr 70 plate should ship with a Mill Test Certificate confirming chemical composition and mechanical test results. For critical applications, Convergence Steel can supply plates tested to ASTM A435 or ASTM A578 Level A/B/C for ultrasonic testing, ensuring internal soundness and freedom from laminations — essential for vessels operating under sustained internal pressure.
Conclusion
SA 516 Grade 70 remains the benchmark PVQ steel for pressure vessels and boilers worldwide. Convergence Steel stocks SA 516 Gr 70 from 8mm to 80mm thickness, in as-rolled or normalized condition, with HIC/NACE testing available on request and full mill documentation on every plate.
